Delta VFD32AMS43ANSAA MS300 Series 15kW 3 Phase 380-480V Compact AC Drive Inverter

Key Specifications

• Brand: Delta
• Model: VFD32AMS43ANSAA
• Series: MS300
• Rated Power: 15kW (20HP)
• Input Voltage: 3-phase AC 380~480V (-15%~+10%), 50/60Hz
• Output Voltage: 3-phase AC 0~480V
• Frequency Range: 0.1~599Hz
• Rated Current: 32A (Heavy Duty HD) / 36A (Normal Duty ND)
• Overload: HD 150%@60s、200%@3s；ND 120%@60s
• Control Mode: V/F、SVC open-loop vector (IM/PM motor)
• Built-in Brake Unit: Yes
• EMI Filter: Not built-in (optional)
• Safety: STO Safe Torque Off, SIL2 / PLd, TÜV certified
• Built-in PLC: 2K steps
• Communication: RS485 Modbus, USB; optional CANopen/Modbus TCP
• Protection: Overcurrent, overload, overvoltage, undervoltage, overheat, stall prevention
• Installation: Wall / DIN rail mount
• Protection Grade: IP20
• Size (W×H×D): 150×260×170mm
• Weight: 8.3kg
• Working Temp: -20℃ ~ 50℃
• Certifications: UL、CE、RoHS、RCM、TUV

Features & Benefits

• Compact E1 frame size saves cabinet space
• 200% low-speed torque at 0.5Hz for reliable heavy-load starts
• Built-in brake chopper enables fast dynamic braking
• STO safety function meets SIL2/PLd machinery safety standards
• Integrated 2K-step PLC reduces external control costs
• USB port for quick parameter copy, ideal for batch setup
• Wide voltage tolerance adapts to unstable industrial grids
